Appearance

Address
2117-3 Yamada, minami-ku,
Okayama-shi 701-0202,JAPAN
Telephone
+81-86-281-1011
Fax
+81-86-281-3011
No.of employee
124
Plant site area
13,760㎡
Building area
Plant : 8,417㎡
Office : 571㎡


Access

emap_okayamaplant.png● Is a car than Seto-ohashi line "Hayashima Station"; 5 minutes
● Is a car than Sanyo main line "Nakasho Station"; 15 minutes
● Is a car than Sanyo Expressway Hayashima I.C; 7 minutes
LinkIconprint

Main faclities

■ Tandem press line
●500t-300t-300t-200t-300t (six axis robot line)

500t×1 ( linked motion ) …………………………Komalsu

300t×3 ( linked motion ) …………………………Aida

200t×1 ( linked motion ) …………………………Aida

Press robot×6………………………………………Nach

●150t-150t-150t-150t

150t×4……………………………………………………Aida

●60t-60t-60t (RY robot line)

60t×3……………………………………………………Aida

Press robot×3………………………………………Orii

●45t-45t-45t-45t-45t

45t×4……………………………………………………Aida

45t×1………………………………………………… Amada


■ Transferpress
●300t…………………………………………………………………Aida

1300 wide Uncoiler transfer (t0.6〜t6.0)……………Orii

●300t…………………………………………………………………Aida

600 wide Uncoiler transfer (t0.5〜t4.5)……………Aida

●250t…………………………………………………………………Aida

BOO wide Uncoiler transfer (t0.6〜t6.0)……………Orii

●200t…………………………………………………………………Aida

SOO wide Uncoiler transfer (t0.6〜t3.2)……………Orii

●11Ot…………………………………………………………………Aida

300 wide Uncoiler transfer (t0.6〜t2.3)……………Orii

●45t…………………………………………………………………Aida


■Transferpress
●300t (7stage)……………………………………………………Komatsu

400×400 Automatic supply system……………Kyodo Engineering


■ Welding machine unit
● CO2 are welding robot×25……………………Daihen, Yasukawa
● Portable spot welding rnachine×41……………………………Toa
● Stationary spot welding machine×41…………………………Toa
● Semi-automatic welding machine×17…………………Matsushita
● automatic welding machine×1 …………………………………Toa
● Multispot welding machine×6………………………Mrtsubishi, ete.
● Multispot welding machine×3………………………………Fujikoshi
● Multi-angle spot welding robot×5O………………………Fujikoshi
■ Jig tool facility
● Mactlining center (1050×640) ×1 ………………………………………OKK

Three dimensional CAD/ CAM×2……………………Graphic Products

Three dimensional CAD×1………………………………………Auto Disc

(CAE PAM-STAMP×1)

● 5V Numerical control milling machine×1………………………Okuma Howa
● Vertical milling machine×1………………………………………Okuma Howa
● NC wire arc welding machine×1…………………………………………Sodec
● NC electrical process machine×1………………………………………Sodec
● Rat surface polisher×2………………………………………OkamotolKuroda
● Contour machine×1…………………………………………………………Amada
● Contour machine×1…………………………………………………………Nagase
● Radial drilling machine×1……………………………………………………Ohya
● Drilling machine×2…………………………………………………………Yoshida
● Drilling machine×1…………………………………………………………Kitagawa
● Electric kiln×1 Amada
● 150t reacton trial dye spotting press×1…………………………………Asai
■ Inspection machine
● CNC three dimensional measuring equipment×1…………………Mitsutoyo
■ Other mechanical facility
● Press brake ×2……………………………………Amada
● Corner shear×1…………………………………Toyo Koki
● Shearing ×1………………………………………Toyo Koki
● Pipe bender ×1………………………………………IHI
● Metal saw ×1………………………………………Amada
● Roll beveling machine×1…………………………Taido
